RM24200

Brand: ChenbroChenbro

Specifications

-
-
-
-
-
-

2U High Flexibility Industrial Server Chassis
With rear access PS/2 PSU, anti-vibration drive cage, and exchangeable front bezel, it is a cost-competitive solution for industrial applications.

Main features

  • Depth 18” of chassis for space-sensitive applications
  • Optimized fan placement for better cooling performance
  • Cushion on drive cages to depress HDD& ODD vibration
  • Removable drive cages for easy installation
  • Supports PS/2 PSU and other standard components to lower TCO

Specifications

MB Form Factor uATX (9.6" x 9.6")
Dimension (D x W x H) 457.0 x 430.0 x 88.1 (mm)18.00" x 16.93" x 3.47"
Drive Bay 2 x External 5.25" ; 1 x External 3.5" ; 1 x Slim ODD ; 2 x Internal 2.5"
Storage Backplane N/A
PSU Form Factor PS/2 Single (Rear)
Indicator 1 x Power Status ; 1 x HDD Activity ; 2 x LAN Activity
Front Control 1 x Power On/Off ; 1 x System Reset ; 2 x USB2.0/ USB3.0 (Option)
Cooling Fan Middle: 80 x 32 mm (1)Rear: 40 x 28 mm (2), Option
System Security Intrusion Switch (Option)
Expansion Slot Opening 4 x Low Profile
Net Weight 6.9 kg/15.2 lb
Gross Weight 9.3 kg/20.48 lb
Cubic Feet 2.50
Container Loading (Single Packing) 20': 388, 40': 788, 40'H: 940
